SSG-2029P-E1CR48H | Supermicro Dual Xeon 2U Storage Server
long delivery time
Advantages:
- Corporate Database
- Database Processing & Storage
- Enterprise Server
- HPC, Data Center, iSCSI SAN
special highlight
Simply Double Rack Server
Up to 2 Addon cards on 2U

- Manufacturer: Supermicro
-
Order number:
1241577
-
Manufacturer SKU:
SSG-2029P-E1CR48H
Configuration not found? Please use our server request form!
Supermicro SSG-2029P-E1CR48H: SuperStorage Architecture with Simply Double 2U Rackmount... more
SSG-2029P-E1CR48H Product Information
Supermicro SSG-2029P-E1CR48H: SuperStorage Architecture with Simply Double 2U Rackmount Server System and up to 50 drive bays
Mainboard:
Supermicro X11DSC+
CPU:
Dual Socket P (LGA 3647), 2nd Gen Intel Xeon Scalable Processors
Up to 28 Cores, support 70-165W TDP
RAM:
24x DIMM slots, up to 6TB RAM DDR4-2933MHz
Supports for Intel Optane DCPMM
LAN:
1x RJ45 dedicated IPMI LAN port
Expansion Slots:
2x PCI-E 3.0 x16 slots
1x PCI-E 3.0 x8 slot
1x PCI-E 3.0 x8 slot + x8 for SAS3 Add-On-Module (AOM)
1x SIOM card support (flexible networking)
Storage:
48x 2.5" hot-swap SAS3/SATA3 drive bays
2x 2.5" hot-swap SATA3 drive bays (rear)
Datasheet for Supermicro SSG-2029P-E1CR48H
Processor/Cache | |
---|---|
CPU | Dual Socket P (LGA-3647) 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡, 3 UPI up to 10.4GT/s Support CPU TDP 70-165W |
Cores | Up to 28 Cores |
Note | ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R) |
System Memory | |
---|---|
Memory Capacity | 24 DIMM slots Up to 6TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM Supports Intel® Optane™ DCPMM†† |
Memory Type | 2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM |
Note | † 2933MHz in two DIMMs per channel can be achieved by using memory †† Cascade Lake only |
On-Board Devices | |
---|---|
Chipset | Intel® C621 chipset |
SAS | SAS3 (12Gbps) via Broadcom 3108; HW RAID RAID 0, 1, 5, 6, 10, 50, 60 |
SATA | SATA3 (6Gbps); RAID 0, 1, 5, 10, 50 |
IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
Video | ASPEED AST2500 BMC |
Input / Output | |
---|---|
Serial ATA | 8 SATA3 (6Gbps) ports |
LAN | 1 RJ45 Dedicated IPMI LAN port |
USB | 2 USB 3.0 ports (rear) 1 Type A |
Video | 1 VGA D-Sub connector port |
Serial Port / Header | 1 Fast UART 16550 port / 1 Header |
System BIOS | |
---|---|
BIOS Type | AMI UEFI |
Management | |
---|---|
Software | Intel® Node Manager IPMI 2.0 KVM with dedicated LAN NMI SSM, SPM, SUM SuperDoctor® 5 Watchdog |
PC Health Monitoring | |
---|---|
CPU | Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator |
FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
Chassis | |
---|---|
Form Factor | 2U Rackmount |
Model | CSE-226STS-R1K62P1 |
Dimensions | |
---|---|
Width | 17.2" (437mm) |
Height | 3.5" (89mm) |
Depth | 30.2" (767mm) Cable Management Arm installed: 35.2" (895mm) |
Gross Weight | 65 lbs (29.5 kg) |
Available Colors | Black |
Front Panel | |
---|---|
Buttons | Power On/Off button System Reset button |
LEDs | Power status LED Hard drive activity LED Network activity LEDs System Information LED Power fail LED |
Expansion Slots | |
---|---|
PCI-Express | 2 PCI-E 3.0 x16 slots 1 PCI-E 3.0 x8 slot 1 PCI-E 3.0 x8 + x8 for SAS3 Add-On-Module (AOM) 1 SIOM card support (flexible networking) |
Drive Bays | |
---|---|
Hot-swap | 48 Hot-swap 2.5" SAS3/SATA3 drive bays 2 Hot-swap 2.5" SATA3 drive bays (rear) |
Backplane | |
---|---|
SAS3 12Gb/s direct attached storage backplane, w/ 24x SAS3 2.5" drive slots |
System Cooling | |
---|---|
Fans | 5x 8cm high-performance PWM fans |
Power Supply | |
---|---|
1600W Redundant Power Supplies with PMBus | |
Total Output Power | 1600W/1000W |
Dimension (W x H x L) |
73.5 x 40 x 203 mm |
Input | 100-127Vac / 13 - 9A / 50-60Hz 200-240Vac / 10 - 8A / 50-60Hz |
+12V | Max: 83.3A / Min: 0A (100-127Vac) Max: 133A / Min: 0A (200-240Vac) |
12Vsb | Max: 2.1A / Min: 0A |
Output Type | 25 Pairs Gold Finger Connector |
Certification | Titanium Level |
Operating Environment | |
---|---|
RoHS | RoHS Compliant |
Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
Order Information | ||
---|---|---|
Manufacturer SKU | SSG-2029P-E1CR48H | |
System Building | SSG-2029P-E1CR48H configured by Supermicro as Complete System |
