Supermicro AS-2124GQ-NART | Dual EPYC 7003 2U GPU Server
long delivery time
Advantages:
- AI/ML, Deep Learning Training and Inference
- High-performance Computing (HPC)
- Cloud Computing
- Research Laboratory/National Laboratory
- Autonomous Vehicle Technologies
- Molecular Dynamics Simulation
special highlight
NVIDIA HGX A100 4-GPU 40GB/80GB, NVLink
- Manufacturer: Supermicro
-
Order number:
1249940
-
Manufacturer SKU:
AS-2124GQ-NART
Configuration not found? Please use our server request form!
Supermicro AS-2124GQ-NART: 2U Ultra SuperServer with latest generation AMD EPYC 3rd... more
AS-2124GQ-NART Product Information
Supermicro AS-2124GQ-NART: 2U Ultra SuperServer with latest generation AMD EPYC 3rd Gen and supports NVIDIA HGX A100 with 4-GPU 40GB/80GB, NVLink
Please note: This barebone is not available individually, but only as a complete system with a minimum configuration. However, the displayed price refers to the barebone without a minimum configuration. Please contact us for an offer of a complete system in your desired configuration.
Mainboard:
Supermicro H12DSG-Q-CPU6
CPU:
Dual AMD EPYC™ 7003/7002 Series Processors, Socket SP3
Up to 128 Cores, supports up to 280W CPU TDP
RAM:
32x DIMM slots, 8TB RAM ECC DDR4 3200MHz SDRAM
LAN:
2x RJ45 10GbE-aggregate host LAN ports
1x RJ45 1GbE dedicated IPMI management port
Expansion slots:
4x PCI-E Gen4 x16 (LP) slots - supporting HGX A100 4-GPU's 1:1 connection to 4 NICs
1x PCI-E Gen 4 x8 (LP) slot
Storage:
4x Hot-swap 2.5" drive bays (SATA/NVMe Hybrid or SAS with optional HBA)
Datasheet for Supermicro AS-2124GQ-NART
| Processor/Cache | |
|---|---|
| CPU | Dual AMD EPYC™ 7003/7002 Series Processors (7003 Series Processor drop-in support requires BIOS version 2.0 or newer) Socket SP3 Supports CPU TDP up to 280W* |
| Cores | Up to 128 Cores (64 per CPU) |
| Note | * Certain CPUs with high TDP may be supported only under specific conditions. |
| GPU Support | Supports HGX A100 4-GPU 40GB (HBM2) or 80GB(HBM2e) with NVLink GPU interconnect and PCI-E Gen4 host CPUs |
| GPU | |
|---|---|
| Supported GPUs | SXM Multi-GPU Board 4-GPU NVIDIA A100 |
| CPU-GPU Interconnect | PCI-E Gen 4 x16 Direct Connect CPU-GPU Dual-Root |
| GPU-GPU Interconnect | NVIDIA® NVLink™GPU-to-GPU Interconnect |
| System Memory | |
|---|---|
| Memory Capacity | 32 DIMM slots Up to 8TB 3DS ECC DDR4-3200MH SDRAM |
| Memory Type | 3200MHz ECC DDR4 SDRAM |
| On-Board Devices | |
|---|---|
| Chipset | System on Chip (SoC) |
| Network | Dual RJ45 10GbE-aggregate host LAN, RJ45 1GbE IPMI |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Graphics & System Management | ASPEED AST2600 BMC |
| Input / Output | |
|---|---|
| SATA | 4 SATA3 (6Gbps) ports |
| LAN | 2 RJ45 10GbE-aggregate host LAN ports 1 RJ45 1GbE Dedicated IPMI management port |
| USB | 2 USB 3.0 ports (rear) |
| Video | 1 VGA Connector (rear) |
| Others | 1 COM port (header) 1 TPM 2.0 (header) |
| System BIOS | |
|---|---|
| BIOS Type | AMI 256Mb SPI Flash ROM |
| Management | |
|---|---|
| Software | IPMI 2.0 KVM with dedicated LAN SSM, SPM, SUM SuperDoctor® 5 Watchdog |
| PC Health Monitoring | |
|---|---|
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator |
| FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis | |
|---|---|
| Form Factor | 2U Rackmountable |
| Model | CSE-228GTS-R2K21P |
| Dimensions | |
|---|---|
| Height | 3.5" (89mm) |
| Width | 17.2" (437mm) |
| Depth | ~32.4" (830.3mm) |
| Weight | Net Weight: 78.5 lbs (35.6 kg) Gross Weight: 88.5 lbs (40.1 kg) |
| Package Dimensions | 45.5" L x 22.5" W x 11" H |
| Available Colors | Black |
| Drive Bays / Storage | |
|---|---|
| Hot-swap | 4 Hot-swap 2.5" drive bays (SATA/NVMe Hybrid or SAS with optional HBA) |
| Expansion Slots | |
|---|---|
| PCI-Express | 4 PCI-E Gen4 x16 (LP) slots - supporting HGX A100 4-GPU's 1:1 connection to 4 NICs 1 PCI-E Gen 4 x8 (LP) slot |
| System Cooling | |
|---|---|
| Fans | 4 Hot-swap heavy duty fans |
| Power Supply | |
|---|---|
| 2200W Redundant Power Supplies with PMBus | |
| Total Output Power | 1000W: 100 – 127Vac 2200W: 220 – 240Vac |
| Dimension (W x H x L) |
107 x 82 x 204 mm |
| Input | 100-127Vac / 12-9.5A / 50-60Hz 220-240Vac / 11-10A / 50-60Hz |
| Output Type | Gold Finger Connector |
| Certification | Platinum Level |
| Operating Environment | ||
|---|---|---|
| RoHS | RoHS Compliant | |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
|
| Order Information | ||
|---|---|---|
| Manufacturer SKU | AS-2124GQ-NART | |
| System Building | AS-2124GQ-NART configured by Supermicro as Complete System | |
